Cat6 UTP Plenum CMP Rated Ethernet Patch Cables

Brand: Custom Cable Connection      SKU: 34416-3BLP

Length
Color
Blue
Black
White
Green
  • Strict building code requirements for cabling in plenum spaces have created installation challenges in settings such as schools, hospitals and other commercial buildings. Custom Cable Connection has expanded its connectivity portfolio to include a line of cables that are ideal for routing through plenum space above dropped ceilings or under raised floors.

    Applications include voice/data/video POE distribution; this cable will handle bandwidth-intensive applications . Meets all Cat6 TIA/EIA standards, and reduces both impedance and structural return loss (SRL) .
    Constructed from high quality plenum cable, this design minimizes Near-End Crosstalk (NEXT) levels.
    • TAA Compliant
    • Assembled in Dallas, TX by Custom Cable Connection
    • Conductor: 4-pair (UTP) 23AWG solid copper
    • Jacket Rating: CMP - Plenum
    • Connectors: 50 micron gold plated RJ45
    • Wired: 568B
    • Tested to 550MHz
    • TIA/EIA-568-C.2
    • RoHS Compliant
    • Power over Ethernet (PoE) Compatible
    • Supports digital lighting management products and IP cameras

    Product Specs

    Cable type: Cat6 Plenum

    Connector type: RJ45 Claw Boot

    Gender: Male to Male

    • For a custom length, call: 866-770-3207 or email: sales@customcableconnection.com
    • Net 30 Terms Available
    • School and Universities automatically approved for Net 30 with PO
    • Quantity discounts and RFQ's available
    • Same day shipping (1PM Cutoff)
    • Sku Barcode Length / Color Weight
      34416-3BLP 810105477979 3ft / Blue 0.2 lb
      34416-3BLKP 810105478112 3ft / Black 0.2 lb
      34416-3WHP 810105478259 3ft / White 0.2 lb
      34416-3GRNP 810105478389 3ft / Green 0.2 lb
      34416-6BLP 810105477986 6ft / Blue 0.25 lb
      34416-6BLKP 810105478129 6ft / Black 0.25 lb
      34416-6WHP 810105478266 6ft / White 0.25 lb
      34416-6GRNP 810105478396 6ft / Green 0.25 lb
      34416-9BLP 810105477993 9ft / Blue 0.29 lb
      34416-9BLKP 810105478136 9ft / Black 0.29 lb
      34416-9WHP 810105478273 9ft / White 0.29 lb
      34416-10WHP 810105478280 10ft / White 0.3 lb
      34416-9GRNP 810105478402 9ft / Green 0.29 lb
      34416-10BLP 810105478006 10ft / Blue 0.3 lb
      34416-10BLKP 810105478143 10ft / Black 0.3 lb
      34416-10GRNP 810105478419 10ft / Green 0.3 lb
      34416-15BLP 810105478044 15ft / Blue 0.41 lb
      34416-15BLKP 810105478150 15ft / Black 0.41 lb
      34416-15WHP 810105478327 15ft / White 0.6 lb
      34416-15GRNP 810105478426 15ft / Green 0.41 lb
      34416-25BLP 810105478051 25ft / Blue 0.45 lb
      34416-25BLKP 810105478167 25ft / Black 0.45 lb
      34416-25WHP 810105478341 25ft / White 0.45 lb
      34416-25GRNP 810105478433 25ft / Green 0.45 lb
      34416-35BLP 810105470345 35ft / Blue 1.9 lb
      34416-35BLKP 810105478174 35ft / Black 1.9 lb
      34416-35WHP 810105478358 35ft / White 2.0 lb
      34416-35GRNP 810105478440 35ft / Green 1.9 lb
      34416-50BLP 810105478082 50ft / Blue 2.2 lb
      34416-50BLKP 810105478181 50ft / Black 2.2 lb
      34416-50WHP 810105470352 50ft / White 3.0 lb
      34416-50GRNP 810105478457 50ft / Green 2.2 lb
      34416-75BLP 810105478099 75ft / Blue 2.5 lb
      34416-75BLKP 810105478198 75ft / Black 2.5 lb
      34416-75WHP 810105470369 75ft / White 3.0 lb
      34416-75GRNP 810105478464 75ft / Green 2.5 lb
      34416-100BLP 810105478013 100ft / Blue 4.0 lb
      34416-100BLKP 810105478204 100ft / Black 4.0 lb
      34416-100WHP 810105478303 100ft / White 4.0 lb
      34416-100GRNP 810105478471 100ft / Green 4.0 lb
      34416-150BLP 810105478020 150ft / Blue 6.0 lb
      34416-150BLKP 810105478211 150ft / Black 6.0 lb
      34416-150WHP 810105478310 150ft / White 5.0 lb
      34416-150GRNP 810105478488 150ft / Green 6.0 lb
      34416-160BLP 810105478037 160ft / Blue 6.2 lb
      34416-160BLKP 810105478228 160ft / Black 6.2 lb
      34416-160GRNP 810105478495 160ft / Green 6.2 lb
      34416-200BLP 810105478068 200ft / Blue 7.0 lb
      34416-200BLKP 810105478235 200ft / Black 7.0 lb
      34416-200WHP 810105478334 200ft / White 8.0 lb
      34416-200GRNP 810105478501 200ft / Green 7.0 lb
      34416-300BLP 810105478105 300ft / Blue 10.0 lb
      34416-300BLKP 810105478242 300ft / Black 10.0 lb
      34416-300WHP 810105478297 300ft / White 9.0 lb
      34416-300GRNP 810105478518 300ft / Green 10.0 lb
