• 12G Rated BNC Male to High Density Micro BNC HD-SDI Belden 4855R Video Adapter Cable
1 6

Custom Cable Connection

12G Rated BNC Male to High Density Micro BNC HD-SDI Belden 4855R Video Adapter Cable

12G Rated BNC Male to High Density Micro BNC HD-SDI Belden 4855R Video Adapter Cable

$47.42 USD
$47.42 USD
Sale Sold out
Shipping calculated at checkout.
Length
Color

SKU: 103827-12G-6INCH
12G Rated! Connect your RED ONE camera with BNC to HD Micro BNC cables.

HD-SDI cables are designed for professional broadcast applications. These cables feature dual copper braided shield for high flexibility, strength, and superb shielding against interference. The center conductor is made from true 75 Ohm 23 AWG solid copper. This cable is 100% sweep tested and is ready to meet today’s requirements of 12 Gbps data transfer.

  • Supports SMPTE 259M/292M/424M Standards
  • Connector A: True 75 Ohm Male BNC
  • Connector B: True 75 Ohm Male Micro HD BNC
  • Number of Coax: 1
  • RG Type: Mini RG59
  • AWG: 23
  • Stranding: Solid
  • Conductor Material: BC - Bare Copper
  • Insulation Material: Gas-injected FHDPE - Foam High Density Polyethylene
  • Outer Shield Material Trade Name: Duofoil®

    Used with Blackmagic Design, Blackmagic HyperDeck Shuttle, Red One, Atomos, and many other patch panels, CCTV devices and cameras."
    • View full details

    Product Specs

    Cable Type: 12G Belden 4855R

    Connector Type: BNC to HD BNC

    Gender: Male to Male

    Additional Info

    • For a custom length, call: 866-770-3207 or email: sales@customcableconnection.com
    • Net 30 Terms Available
    • School and Universities automatically approved for Net 30 with PO
    • Quantity discounts and RFQ's available
    • Same day shipping (1PM Cutoff)
    Sku Barcode Length / Color Weight
    103827-12G-6INCH 810105470536 6 Inch / Black 0.2 lb
    103827-12G-1 810105470550 1ft / Black 0.23 lb
    103827-12G-1.5 810105473797 18" / Black 0.24 lb
    103827-12G-2 810105470079 2ft / Black 0.25 lb
    103827-12G-3 810105470086 3ft / Black 0.26 lb
    103827-12G-4 4ft / Black 0.27 lb
    103827-12G-5 810105470093 5ft / Black 0.3 lb
    103827-12G-6 810105470543 6ft / Black 0.35 lb
    103827-12G-6PUR 6ft / Purple 0.2 lb
    103827-12G-7 7ft / Black 0.5 lb
    103827-12G-15 810105473810 15ft / Black 0.7 lb
    103827-12G-10 810105470567 10ft / Black 0.4 lb
    103827-12G-25 25ft / Black 1.3 lb
    103827-12G-30 30ft / Black 1.5 lb
    103827-12G-40 40ft / Black 1.0 lb
