Custom Cable Connection

BNC Female to HD Micro BNC 3G/6G HD-SDI Video Adapter Cables

BNC Female to HD Micro BNC 3G/6G HD-SDI Video Adapter Cables

Regular price $29.00 USD
Regular price Sale price $29.00 USD
Sale Sold out
Shipping calculated at checkout.
Length
Color
Standard BNC Female to High Density Micro BNC cables are designed for professional broadcast applications. Adapt your Standard BNC connections to High Density Micro BNC with this adapter cable. These cables feature dual copper braided shield for high flexibility, strength, and superb shielding against interference. The center conductor is made from true 75 Ohm 23 AWG solid copper. This cable is 100% sweep tested and is ready to meet today’s requirements of 3/6 Gbps data transfer.

  • HD Micro BNC— Delivers true 75 Ohm performance in a footprint 51% smaller than traditional BNC connectors allowing four times the density
  • Supports SMPTE 259M/292M/424M Standards
  • Connector A: True 75 Ohm Standard BNC Female
  • Connector B: True 75 Ohm High Density Micro BNC Male
  • Number of Coax: 1
  • RG Type: Mini RG59
  • AWG: 23
  • Stranding: Solid
  • Conductor Material: BC - Bare Copper
  • Insulation Material: Gas-injected FHDPE - Foam High Density Polyethylene
  • Outer Shield Material Trade Name: Duofoil®

    Used with Blackmagic Design, Blackmagic HyperDeck Shuttle, Red One, Atomos, and many other patch panels, CCTV devices and cameras.
  • View full details

    Product Specs

    Cable Type: Mini RG59

    Connector Type: BNC (F) to HD BNC

    Gender: Female to Male

    Additional Info

    • For a custom length, call: 866-770-3207 or email: sales@customcableconnection.com
    • Net 30 Terms Available
    • School and Universities automatically approved for Net 30 with PO
    • Quantity discounts and RFQ's available
    • Same day shipping (1PM Cutoff)
    Sku Barcode Length / Color Weight
    103829-6INCH 810105470963 6 Inch / Black 0.15 lb
    103829-1 810105470185 1ft / Black 0.17 lb
    103829-18INCH 810105470970 18 Inch / Black 0.2 lb
    103829-2 810105470215 2ft / Black 0.3 lb
    103829-3 810105470987 3ft / Black 0.3 lb
    103829-5 810105470994 5ft / Black 0.3 lb
    103829-75 75ft / Black 4.0 lb
    103829-6 810105471007 6ft / Black 0.5 lb
    103829-100 100ft / Black 6.0 lb
    103829-10 810105471014 10ft / Black 1.0 lb
    103829-15 810105471021 15ft / Black 0.5 lb
    103829-25 810105471038 25ft / Black 2.5 lb
    103829-35 810105471045 35ft / Black 3.5 lb
    103829-40 810105471052 40ft / Black 4.0 lb
    103829-50 810105471069 50ft / Black 5.0 lb
