The All New 12G RG-7 from Belden Engineered specifically to optimize transmission distance, Belden 4794R exceeds the SMPTE Return Loss (RL) specifications for UHDTV providing significant headroom and guaranteeing -15 dB RL from 4.5 to 12GHz. Upgraded manufacturing machinery, new braid design, silver-plated copper conductor, and a new polyethylene formula are all design features that contribute to significant RL improvement and an 8 dB improvement on cable attenuation compared to existing coaxes.
Belden 4794R maximizes 4K transmission distance over a single coax while minimizing space and weight compared to multi-link solutions.
Conductor
AWG: 16 AWG Solid Coax
Conductor Material : Silver Plated Copper 0.051
Total Number of Conductors: 1
Shielding
Belden 4794R features tri-shield (foil / braid / foil) for superior performance
