Custom Cable Connection

Din 1.0/2.3 to Din 1.0/2.3 Right Angle HD-SDI 6G Coaxial Cable

Din 1.0/2.3 to Din 1.0/2.3 Right Angle HD-SDI 6G Coaxial Cable

$42.00 USD
$42.00 USD
Sale Sold out
Shipping calculated at checkout.
Length
Color
Mini RG59 HD-SDI cables are designed for professional broadcast applications. These cables feature dual copper braided shield for high flexibility, strength, and superb shielding against interference. The center conductor is made from true 75 Ohm 23AWG solid copper. This cable is 100% sweep tested and is ready to meet today’s requirements of 3/6 Gbps data transfer.

  • Supports SMPTE 259M/292M/424M Standards
  • Connector A: True 75 Ohm Din 1.0/2.3 Male
  • Connector B: True 75 Ohm Din 1.0/2.3 Male Right Angle
  • Number of Coax: 1
  • RG Type: Mini RG59
  • AWG: 23
  • Stranding: Solid
  • Conductor Material: BC - Bare Copper
  • Insulation Material: Gas-injected FHDPE - Foam High Density Polyethylene
  • Outer Shield Material Trade Name: Duofoil®

    Used with Blackmagic Design, Blackmagic HyperDeck Shuttle, Red One, Atomos, and many other patch panels, CCTV devices and cameras.
    • View full details

    Product Specs

    Cable Type: Belden 1855A - Mini RG59

    Connector Type: 1.0/2.3 Din to Din Right Angle

    Gender: Male to Male

    Additional Info

    • For a custom length, call: 866-770-3207 or email: sales@customcableconnection.com
    • Net 30 Terms Available
    • School and Universities automatically approved for Net 30 with PO
    • Quantity discounts and RFQ's available
    • Same day shipping (1PM Cutoff)
    Sku Length / Color Weight
    116206-6INCH 6 Inch / Black 0.2 lb
    116206-1 1ft / Black 0.25 lb
    116206-2 2ft / Black 0.28 lb
    116206-3 3ft / Black 0.3 lb
    116206-5 5ft / Black 0.33 lb
    116206-6 6ft / Black 0.5 lb
    116206-10 10ft / Black 1.0 lb
    116206-15 15ft / Black 1.5 lb
    116206-25 25ft / Black 2.0 lb
